Background on AMD EPYC 4004 Series CPUs
AMD's EPYC 4004 are entry-level server processors that utilize their "Zen 4" architecture and are built on a 5nm manufacturing process. These CPUs are certified across a wide range of operating systems and workloads, and include support for popular technologies like DDR5 memory, AVX-512, and PCI Express 5.0.
Please note that models ending in an "X" utilize AMD's 3D V-Cache, which provides more and higher-performance L3 cache memory compared to other versions along with slightly different base and boost clock speeds.
Model: AMD 100-000001478
Specifications
| Product Line | EPYC |
| Code Name | Raphael |
| Socket | AM5 |
| Process | 5 nm |
| Total Number of Threads | 24 |
| Total Number of Cores | 12 |
| Base Clock Speed | 3.7 GHz |
| Simultaneous Multi-Threading | Yes |
| Turbo Boost | Yes |
| Max. Turbo Boost | 5.4 GHz |
| Thermal Output | 65 W |
| PCI-E Lanes | 24 |
| Max Temperature | 95 C |
Cache | |
| L2 | 12MB |
| L3 | 64MB |
Onboard Graphics | |
| Processor Type | Radeon Graphics |
| Core Speed | 2,200 MHz |
| DirectX Version | 12 |
| Cores on Die | 2 |
| # of Displays Supported | 3 |
Memory Specification | |
| Memory Type | DDR5 |
| Maximum Frequency | 5200 |
| Registered Support | No |
